YQK- 40H30纸箱自动成型封底机卧式开箱机
YQK- 40H30纸箱自动成型封底机卧式开箱机
...........................................................................................................................................................................................................................................................................................................................................................................................
...........................................................................................................................................................................................
......................................................................................................................................................................................
产品操作视频
...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
产品操作视频
........................................................................................................................................................................................................................................................................................................................................
YQK-40H 30 （纸箱自动成型封底机） 自动开箱机
主要技术参数
| 机器型号：YQK-40H 30 （纸箱自动成型封底机） 自动开箱机 |
| 开箱能力：30箱/分钟 |
| 纸箱暂存量：80PCS（800MM） |
| 包装纸箱尺寸：L:240-510 W:190-400 H:120-400MM |
| 使用电气：380V 3ф 746W |
| 必要空气压：5KG/cm2 |
| 空气消耗量：300NL/min |
| 机械尺寸：L2372*W1210*H1820MM |
| 机械重量：1000KG |
| 胶带尺寸：48、60 |
| 最小规格不能一同存在 |
